The Helix Interactive Flat Panel replaces a projector, whiteboard, computer, camera, and speaker system with one feature-packed 4K touch display. It's a full-function interactive flat panel built for classrooms, meeting rooms, and training environments, with zero-gap touch writing, a built-in Android 14 system, an integrated camera and microphone, and an optional Windows OPS module for teams that need it.
High resolution display quality, precise touch, flexible computing, wireless sharing, and effortless collaboration combined into one seamless workplace.
Ultra HD resolution with detailed clarity rendering for crystal-clear visuals.
Built-in Android 14, optional Windows OPS module expansion if required.
System menus and settings can be displayed in Hausa, Igbo, or Yoruba.
Anti-reflective, scratch-resistant surface for enhanced clarity and true-to-life imaging.
Bring lessons and ideation sessions to life using built-in, subject-specific digital tools.
Scan a QR code to save whiteboard sessions instantly, share by email, or save locally.
Zero-gap technology and high-precision IR touch; dual pens with distinct colour outputs for more effective collaboration.
Real-time sharing with no cables, from up to 9 devices at once, across Android, Windows, Chromebook, and iOS.
Auto-focus, auto white balance, 3D noise reduction; Zoom, Microsoft Teams, Google Meet, and Webex compatible.
Control your USB-C connected laptop directly from the board. No need to go back and forth to your connected device.
Run parallel tasks and wider working scenes side by side with full functionality in each window.
Combines everything needed for teaching, presentations, and collaboration into a single, powerful all-in-one device.
Helix IFP37 Series
The Helix IFP37 Series is built to transform how you present, teach, and collaborate. From engaging interactive lessons to data-driven, high-stakes presentations and virtual meetings, its robust hardware, intuitive software, and seamless connectivity make every session impactful.
Complete specification data for the 55, 65, 75, and 86-inch models.
|
Screen Size
|
55"
 |
65"
|
75"
|
86"
|
|---|---|---|---|---|
|
Operating system
|
Android 14 with optional Windows 10 or 11 via OPS module (OPS module dimensions: 120×180×30mm / 195×180×30mm / 195×180×42mm). Hausa, Igbo, or Yoruba selectable as OS language, in addition to English and other standard languages.
|
|||
|
Processor
|
MediaTek MT9679: 1.5GHz main frequency/ Quad-core A73 CPU/ G52MC1 GPU/ 8GB RAM/ 128GB ROM.
|
|||
|
Resolution
|
3840×2160 (4K UHD)
|
3840×2160 (4K UHD)
|
3840×2160 (4K UHD)
|
3840×2160 (4K UHD)
|
|
Display area
|
1209.6 × 680.4mm
|
1429 × 804mm
|
1651 × 929mm
|
1896 × 1067mm
|
|
Display
|
8ms response time, 16:9 aspect ratio, 60Hz refresh, 1.07B colours (10-bit), 72% NTSC, DLED backlight, ≥30,000 hour lifetime
|
|||
|
Pixel pitch
|
0.315 × 0.315mm
|
0.372 × 0.372mm
|
0.42975 × 0.42975mm
|
0.4935 × 0.4935mm
|
|
Brightness (typ)
|
240 cd/m²
|
300 cd/m²
|
320 cd/m²
|
320 cd/m²
|
|
Contrast ratio
|
up to 4500:1
|
up to 5000:1
|
up to 6000:1
|
up to 6000:1
|
|
Viewing angle
|
178° (H/V)
|
178° (H/V)
|
178° (H/V)
|
178° (H/V)
|
|
Touch system
|
IR sensing, 40-point touch (Android and PC), ±2mm accuracy (over 90% of touch area), ≤3mm writing height, ≤8ms response, opaque-object touch tools (finger or stylus), single stylus pen with two colour outputs, 32767×32767 interpolation resolution. Compatible with Windows 11/10/8/7/XP, Android, Linux, Mac OS X, and Chrome.
|
|||
|
Wireless
|
Wi-Fi 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz), Bluetooth 5.4, 0–10m operating distance on both.
|
|||
|
Camera & microphone
|
Integrated; automatic white balance and 3D noise reduction; supports echo cancellation, background noise suppression, gain compensation, sound source localisation and portrait tracking. 0–8m pickup distance, 0°–180° pickup angle.
|
|||
|
Audio
|
2.0-channel sound, 2×16W speakers.
|
|||
|
Ports (front)
|
2× USB (one 3.0, one 2.0), 1× HDMI in, 1× touch USB, 1× USB-C (full function), 1× physical key.
|
|||
|
Ports (onboard)
|
1× RJ45, 1× RS232, 1× optical out, 1× mic in, 1× line out, 1× USB 3.0, 1× touch out, 2× HDMI, 1× USB 2.0.
|
|||
|
Net weight
|
27.5±1kg
|
37±1kg
|
51.4kg
|
67±1kg
|
|
Gross weight
|
34.5±1kg
|
42.55±1kg
|
64.4±1kg
|
80.2±1kg
|
|
Dimensions (L×W×T)
|
1263 × 793.6 × 103.4mm
|
1484.6 × 919.9 × 116mm
|
1706.8 × 1044 × 116mm
|
1953 × 1184.4 × 116mm
|
|
VESA mount
|
400×400mm
|
500×400mm
|
600×400mm
|
800×400mm
|
|
Wall-hanging screws
|
M6 × 16mm
|
M8 × 20mm
|
M8 × 20mm
|
M8 × 20mm
|
|
Max power
|
157.5W
|
163.5W
|
214.6W
|
251.7W
|
|
Power requirements
|
100–240V~, max 90–264V~, 50/60Hz, 2.8A
|
100–240V~, max 90–264V~, 50/60Hz, 2.8A
|
100–240V~, max 90–264V~, 50/60Hz, 3.5A
|
100–240V~, max 90–264V~, 50/60Hz, 5.0A
|
|
Environmental
|
Operating temperature 0–40°C, operating humidity 10–90% RH, storage temperature -20–60°C, storage humidity 10–90% RH, max altitude 5000m.
|
|||
|
In the box
|
Power cord, stylus pen, wall mount, remote control, quick start guide.
|
|||
Helix is IT&C Networks’ proprietary technology brand. Interactive flat panels, tablets, power systems, and charging infrastructure, designed to bring full-featured classroom and office technology within reach for more West African schools, offices, and institutions.
Helix is a trademark of IT&C Networks Ltd. Product features and specifications are subject to change without notice.
