The Helix Power Hub is an all-in-one solar energy system designed as the heartbeat of your operational environment, ensuring that a disruption in grid power never means a pause in momentum. Built around high-density Lithium Iron Phosphate architecture, it bridges the gap between clean energy capture and high-demand technology, seamlessly sustaining interactive digital displays during crucial meetings and lessons, energizing centralized device charging infrastructures, and maintaining continuous uptime for your critical devices.
Compact, high-capacity all-in-one solar energy systems designed to deliver quiet, clean backup power for smart classrooms, office workstations, homes, and mobile field operations.
Designed to power critical electronic devices including laptops, Helix Interactive Flat Panels, Helix Smart Charging Carts, network routers, LED lighting, TV setups, and field survey equipment, with negligible operating noise, no fumes, and no fuel costs.
Integrated pure sine wave inverter, lithium battery, and high-efficiency Maximum Power Point Tracking (MPPT) solar charge controller in a single portable enclosure. Charge via direct solar panel input, or grid or generator AC power.
Supports wide-range AC input (90VAC–280VAC) for rapid utility or generator charging, combined with a high-current MPPT solar charge controller accepting up to 300W of solar input on the Power Hub 500 and up to 550W on the Power Hub 1000.
Compact footprint featuring built-in carrying handles, direct USB 5V/1A output, and fast AC plug points for quick deployment in schools, offices, remote sites, and homes.
Built with long-life 3.2V 314Ah Lithium Iron Phosphate (LiFePO4) cell technology. Enjoy thousands of recharge cycles with high thermal stability and zero maintenance.
Provides up to 1 kWh of energy storage on the Power Hub 500 and 2 kWh on the Power Hub 1000. Available in two distinct capacities, the series lets you precisely tailor backup power to your requirements.
Built-in overcurrent, overvoltage, over-temperature and short-circuit protection safeguards both your connected equipment and the battery.
An intelligent, energy-saving air-cooling design keeps the Power Hub running efficiently at 50 dB or less, and it operates from -10 to 40 °C.
Ideal for Small Workstations, Micro Businesses, Charging Kiosks & Field Data Teams. Key Specs:
Heavy-Duty Backup for Executive Suites, Office Pods & Smart Classrooms with interactive flat panels. Key Specs:
Detailed technical specifications for the Power Hub 500 and Power Hub 1000
|
DEVICE NAME
|
Helix POWER HUB 500
|
Helix POWER HUB 1000
|
||
|---|---|---|---|---|
|
Rated Output Power
|
500W
|
1000W
|
||
|
AC Output
|
230VAC ±5V, 50Hz ±0.5%, Pure Sine Wave
|
230VAC ±5V, 50Hz ±0.5%, Pure Sine Wave
|
||
|
Output Power Factor
|
≥ 0.99
|
≥ 0.99
|
||
|
Total Harmonic Distortion (THD)
|
< 3% (linear load), < 5% (non-linear load)
|
< 3% (linear load), < 5% (non-linear load)
|
||
|
AC Input (Grid/Gen)
|
230VAC; 90VAC–280VAC wide input; 45–65Hz
|
230VAC; 90VAC–280VAC wide input; 45–65Hz
|
||
|
Changeover Time
|
≤ 20ms
|
≤ 20ms
|
||
|
Battery Chemistry
|
Premium LiFePO4 (Lithium Iron Phosphate)
|
Premium LiFePO4 (Lithium Iron Phosphate)
|
||
|
Battery Voltage and Capacity
|
3.2VDC, 314Ah
|
6.4VDC, 314Ah
|
||
|
Battery Storage Energy
|
1,004 Wh (~1 kWh)
|
2,009 Wh (~2 kWh)
|
||
|
Max Battery Charging Power
|
500W
|
1,000W
|
||
|
AC + PV Max Charging Current
|
1–140A (configurable)
|
1–160A (configurable)
|
||
|
PV Solar Input Voltage Range
|
11VDC – 55VDC
|
11VDC – 55VDC
|
||
|
Max PV Solar Power Input
|
300W
|
550W
|
||
|
Max PV Input Current
|
10A
|
15A
|
||
|
Max PV Charge Current
|
80A
|
100A
|
||
|
DC Auxiliary Output
|
USB 5V / 1A
|
USB 5V / 1A
|
||
|
Communication and Monitoring
|
USB serial interface
|
USB serial interface
|
||
|
Operating Temperature
|
-10 to 40 °C
|
-10 to 40 °C
|
||
|
Storage Temperature
|
-15 to 60 °C
|
-15 to 60 °C
|
||
|
Humidity
|
5–95% (non-condensing)
|
5–95% (non-condensing)
|
||
|
Noise
|
≤ 50 dB
|
≤ 50 dB
|
||
|
Working Altitude
|
Up to 3,000m (10% derating per 1,000m above)
|
Up to 3,000m (10% derating per 1,000m above)
|
||
|
Dimensions (L × W × H)
|
255 × 155 × 315 mm
|
285 × 230 × 315 mm
|
||
|
Net / Gross Weight
|
10.7 kg / 11.5 kg
|
19 kg / 20 kg
|
||
|
Solar Panel Specification
|
300W Monocrystalline
|
580W Monocrystalline
|
||
|
Solar Cable Included
|
4mm² PVC Single Core Solar Cable
|
4mm² PVC Single Core Red & Black (100m Roll Options)
|
||
